Recycled Bottle Flakes PET Strap Making Machine 200KW Strapping Band Making

  • 1
  • 2

Brand Name : JIATUO

Model Number : JTPET-90

Certification : CE, ISO

Place of Origin : Shenzhen, China

MOQ : 1 Set

Price : Negotiable

Payment Terms : L/C, D/A, T/T, Western Union, MoneyGram

Supply Ability : 50 set/month

Delivery Time : 50~55 working days

Packaging Details : plastic film or other standard package for sea shipping

Product type : PET Strap Making Production Line

Raw material : PET Flakes Or 100% Recycled Material

PET Strap Width : 9-32mm

PET thickness Range : 0.6-12mm

Capacity : 200kg/h

Driven Type : Electric

Motor : Siemens

Voltage : According To Customer's Factory

Product Color : Green/Pink/yellow/black

Application : Packaged Material

After-sales service provided : Video technical support, Online support

Warranty : 1 Year

Contact Now

Green Recycled Bottle Flakes PET Strapping Fully Automatic Packing Machine Extrusion Line


PRODUCT DESCRIPTION

PET strap, also known as plastic steel band, which is used in place of steel on the world of a new environmentally friendly packaging materials, the development of new materials in recent years the cost of success and a substantial decline, have been widely used in the steel industry, chemical fiber industry, aluminum ingots, paper, brick kiln industry, screw industry, tobacco industry, electronics, textiles and wood, etc.; It is replaced by a new high-strength steel strapping, is the world’s most widely used for steel products with high strength.

PET Strap Production Line Machine List

NO. Item Specification
1 Power According to customer's factory voltage
2 Material PET raw material or 100% PET bottle flakes recycled
3 Capacity

PETJT90:200kg/h

PETJT100:250kg/h

PETJT125:350kg/h
4 Product size

Width:9-32mm

Thickness:0.6-12mm
6 Mid-height of extruder 7000mm
7 Installation power

PETJT90:200KW

PETJT100:250KW

PETJT125:300KW
8 Humidity <85%
9 Temperature 0-40 degree
10 Cooling tower capacity 30T/H or 50T/H
11 Installation Dimensions

PETJT90:45*2.0*7.0M

PETJT100:45*2.0*7.0M

PETJT125:60*3.0*8.0M
12 Product color Green/Black/Pink/Yellow
13 Factory dimension

35m*(3~6)m*(4~6)m

45m*(3~6)m*(4~6)m

If your factory not big enough,please contact with us,our engineer can according to your size to design

Recycled Bottle Flakes PET Strap Making Machine 200KW Strapping Band Making

Features of PET packing strap production line:

  • 1. Better tensile strength: the PET strap production line has the tensile strength of the steel belt, and the ductility is good, and the anti-impact performance is better. It is not easy to break, and it can ensure the safety of product transportation.
  • 2. Small extension: Although PET strap is one kind of plastics, its extension of change is very small, its elongation is only 1/ 6 of polypropylene, it can maintain tension force, after the packing make the expansion no longer change.
  • 3. Strong temperature resistance: the experiment proved that the melting point of PET packing belt at about 260 ℃, can be used under the environment of 120 ℃ for a long time not to distort,it has a good stability.
  • 4. Good economic benefit: the density of PET packaging belt is 1.30 ~ 1.38 g/cm3, which is only 1/6 of the steel belt density (7.8 g/cm3), which is equivalent to the length of the 6-ton steel belt, and the price of the same unit length is relatively low.
  • 5. Environmentally friendly: the steel belt will rust due to exposure to the air, and the rust is highly permeable to the packaging. PET packing tape is beautiful and not rusted, but avoid unnecessary worry. It can also be recycled.
  • 6. Good flexibility and safe operation: the PET packing strip has no sharp edge with steel belt, it will not scratch the package, and it will not hurt the hand. You don’t need a special tool when you cut it, even if it’s tight, it doesn’t hurt when you cut it.
  • 7.High quality packaging ideal products: PET packaging with all kinds of bright colors, shiny, high quality, the most ideal packaging products of high-end packaging

Recycled Bottle Flakes PET Strap Making Machine 200KW Strapping Band Making

Recycled Bottle Flakes PET Strap Making Machine 200KW Strapping Band Making
